Standard Abrasives S/C Straight Cartridge Roll 709947 1/4" x 2" x 1/8" 80 Grit
Standard Abrasives Straight Cartridge Roll 709947
1/4 x 2 x 1/8 80 Grit Silicon Carbide Straight Cartridge Roll
Mfg suggested alternative 3M 7010362466.
$0.86 Per Piece
Description
Standard Abrasives S/C Straight Cartridge Roll 709947 1/4" x 2" x 1/8" 80
In coarse grades, the Standard Abrasives Silicon Carbide Cartridge Roll is used for high-speed grinding and deburring on all metals, as well as glass and composites. Its small size and shape enable it to reach into holes and diameters of machined parts or deburr irregular surfaces and contours. Super sharp silicon carbide suits hard-to-grind metals such as titanium, as well as softer surfaces.
Running a Cartridge Roll on a High-Speed Tool The cartridge roll has an arbor hole to accommodate a mandrel tool attachment (sold separately), which attaches to a rotary tool such as a die grinder or drill. The mandrel should have a pilot length no less than 1/2" shorter than the length of the cartridge roll.
Super Sharp Silicon Carbide Leaves a Fine Finish Silicon Carbide is harder and sharper than either aluminum oxide or zirconia alumina. It is most commonly used for low-pressure applications such as paint prep and the final stages of whitewood sanding. While it may have a shorter life than aluminum oxide, it produces a superior finish and should be used when a fine scratch pattern is desired.
Tech Specs
| AA Item# | 51115341298 |
|---|---|
| Manufacturer: | Standard Abrasives |
| Standard Abrasives Part# | 709947 |
Standard Abrasives Straight Cartridge Roll 709947 - 1/4 x 2 x 1/8 80 Grit Silicon Carbide Straight Cartridge Roll
Cartridge Roll Manufacturer - Product Line: Standard Abrasives Straight Cartridge Rolls - S/C
Standard Part Number - 709947
Standard UPC - 51115341298
Cartridge Roll Size: 1/4x2x1/8
Cartridge Roll Arbor Hole: 1/8" Arbor Hole
Cartridge Roll Grit: 80 Grit
Cartridge Roll Grain: Silicon Carbide
Standard Abrasives Silicon Carbide Cartridge Rolls have sharp cutting points that provide rapid cutting action making this roll best for non-ferrous metals. The multi-layer, multi-wear design of Standard Abrasives Cartridge Rolls keeps it cutting sharp and helps it withstand repeated wear. As top layers wear down over time, underlying layers expose fresh mineral, so you get a consistent cut, part after part.
