Kalamazoo KS390 3x90 Sander 2HP-1PH or 3HP- 3PH

Kalamazoo KS390 - 3X90 SANDER 2HP-1PH OR 3HP- 3PH

Need to clean castings regularly? With a belt speed of 7200 FPM and a 3HP or 2HP motor, the KS490 4 x 90 inch industrial grinder will hog off iron quick and cool. The belt grinder head is adjustable to accommodate work height. A hinged panel on the side of the grinder head allows for a quick and easy part and sanding belt replacement.

• Powerful 2 HP- 1PH 230V (only) and or 3 HP 3 PH 230V or 460V motor (specify at time of order).
• 1PH amps: 115V 23 amps and 230V 11.5 amps
• 3PH amps: 208V 7.9 amps, 230V 7.2 amps and 460V 3.6 amps
• 24-1/2″ long steel reversible and replaceable platen.
• Direct drive.
• Replaceable contact wheel specifications: 8″ OD x 4″ W serrated 70 duro with sealed ball bearings.
• On/off switch.
• Belt size: 4″ x 90″. All belt types can be used.
• Spring belt tension.
• Quick release belt tension release lever.
• Easy belt tracking.
• Material stop.
• Removable steel platen guard.
• Adjustable steel work table.
• Adjustable belt grinder head.
• Hinged door on grinder head for quick belt and change.
• Multi-position horizontal through vertical.
• Steel base.
• Belt speed: 7200 SFPM
• Machine shipping dimensions: L 48″ x W 57″ x H 52″

DESIGNED TO THE FOLLOWING

• Bevel
• Deburr
• Squaring up ends
• Rounding corners
• Flatwork
• Contouring
• Heavy metal removal
• Aggressive grinding
• Sharpening
• Clean castings
• Hog off iron
