CS Unitec MAB 155PRO Ultra Compact Magnetic Drill

AA Item#
MAB 155PRO
CS Unitec Part#
MAB 155PRO
Manufacturer
CS Unitec
CS Unitec MAB 155PRO Ultra Compact Magnetic Drill
CS Unitec MAB 155PRO Ultra Compact Magnetic Drill

Image may not be exact product match.

none

CS Unitec MABasic 400 Portable Magnetic Drill

Use with Annular Cutters up to 1-1/2” Diameter. Stroke length 1-1/2"

This item qualifies toward free freight
Free ground shipping on qualified web store order $250.00 and over!
$1,251.45
Per 1 Piece Package
$1251.45 Per Piece
In stock

Enter # of Packages

Description

AA Item#
MAB 155PRO
CS Unitec Part#
MAB 155PRO
Manufacturer
CS Unitec

CS Unitec Two-Speed Portable Magnetic Drill MABasic 400

MAB 155PRO Features:

  • LED light for increased visibility
  • Rear mounted control for ergonomics and easy access
  • Ultra compact at only 7-1/8" high
  • Ratchet-style advancing mechanism for work in spaces with limited clearance
  • Advancing lever can be mounted on either left or right side
  • Accepts cutters with a 3/4" weldon shank and a maximum depth of cut of 1-1/2"
  • Internal cable routing
  • Simple, ergonomic arrangement of controls for one-handed operation
  • Emergency-off function: electronic safety sensor shuts down drill motor if magnet loses contact with material to protect operator and equipment

MAB 155PRO Includes:

  • 1 Magnetic Drilling Machine
  • 1 Pilot Pin
  • 1 Plastic Carrying Case
  • 1 Safety Chain
  • 1 Hexagon Socket Screw Key SW 4
  • 1 Operating Manual
  • 1 Warranty Certificate
  • 1 Safety Strap
  • 1 Carabin Hook
  • 1 Allen Key

Tech Specs

More Information
AA Item# MAB 155PRO
Manufacturer: CS Unitec
CS Unitec Part# MAB 155PRO

CS Unitec MAB 155PRO Ultra Compact Magnetic Drill Specifications

Model: MAB 155PRO

Motor Power: 9.5 Amp/110 Volt

Stroke: 1-1/2" dia.

Hole Capacity: 1-1/2" dia.

Speeds: 320 RPM

Magnet Base Size: 3.15" x 7.28" x 1.52"

Dimensions: 7-3/32" H x 13-5/16" L x 4-3/4" W

Magnetic Force (1"Plate): 2640 lbs.

Arbor Bore: 3/4" Weldon Shank

Equipped with LED light for increased visibility
